Why an accurate survey matters
- Planning drawings based on guesswork can be rejected or cause problems on site
- Structural engineers and builders need real dimensions to design and price accurately
- Small errors in wall thickness or floor levels become expensive mistakes later
What we record
- Room dimensions, wall thicknesses, and door and window positions
- Floor-to-ceiling heights and floor levels
- Roof shape and pitch, loft space and chimneys
- External elevations and boundaries
- Visible drainage, manholes and services
- Photographs throughout
- Constraints worth knowing about early: trees, neighbouring windows, level changes
What you receive
| Drawing | Purpose |
|---|---|
| Existing floor plans | The base for every design option |
| Existing elevations | Needed for planning submissions |
| Existing sections | Show heights, levels and roof structure |
| Roof plan and site plan | Show the context and boundaries |
Formats: PDF and DWG as standard, with a Revit (BIM) model available · Method: laser measurement and 3D scanning · Ownership: the drawings are yours to keep.
How it works
- Book: a quick call to understand your project and arrange access
- Visit: within 1–3 days of booking, or on a date that suits you
- Drawings: your existing drawings are ready 2–3 days after the visit
- Next step: the survey goes straight into concept design
Prices
| Survey | DWG (AutoCAD) | Revit (BIM) |
|---|---|---|
| House, up to 4 bedrooms | £450 | £525 |
| House, up to 6 bedrooms | £600 | £675 |
Save with a bundle: book your survey with building regulations drawings and the second item is half price, from £750 for both.
Surveys cover London, Essex, the Midlands and the South of England. Prices are final: there's no VAT to add.
